Pioneer DDJ REV1 Professional 2-Channel DJ Controller for Serato DJ Lite - Perfect for Scratching, Mixing & Home Parties

Join the Revolution

The DDJ-REV1 matches perfectly with the free Serato DJ Lite software, boasting a brand-new battle-style layout that’s easy to use and perfect for playing like a pro. The design of this 2-channel DJ controller emulates a professional DJM-S mixer + PLX turntable setup, including specialized features for open-format and scratch DJs.

Brand-new battle-style layout

Get hands-on with an interface designed to emulate 2 x PLX turntables and a DJM-S series mixer – the kind of setup used by pro battle DJs. There’s plenty of space to perform mixing and scratching techniques thanks to the new arrangement of the controls on the DDJ-REV1. The tempo sliders are 60mm – longer than those on the DDJ-SB3 to give you finer control – and they run horizontally above the decks while the Performance Pads have been moved into the mixer section so you can intuitively combine effects, trigger samples, and scratch your tracks.

Bigger jog wheels

The bigger the jog wheels, the better for scratching. The jogs on the DDJ-REV1 are the same size as the ones on the DDJ-SR2, a popular controller that’s higher up in our range.

Lever FX

Dynamically add texture to the music with Lever FX. Pull the levers down and hold them to apply effects from Serato DJ Lite in short bursts or push them up to lock on effects and free up your hands for scratching or track browsing.

Tracking Scratch: Get a helping hand with scratching

The Tracking Scratch feature silently takes the music back to the cue point the moment you move the jog wheel from backward to forward or lift your hand away – saving you from closing the fader and finding the right place in the music to start the scratch again. All you need to do is to select the Tracking Scratch Pad mode, press a Performance Pad to choose the Scratch Crossfader Cuts pattern you want to use, then start moving the jog.

Mixed microphone audio: Easily add your voice while you’re streaming

For the first time in a Pioneer DJ controller at this level, the output of the master audio is mixed with the sound from the microphone if you have one plugged in. This means you don’t need any external equipment such as a soundcard or separate mixer if you want to add speech or vocals to your performance and route it through your computer. All sounds are sent to Serato DJ Lite so you can stream from there.

Serato DJ Lite integration: Enjoy full use of the free software

As soon as you’ve downloaded Serato DJ Lite to your PC/Mac for free, you can simply connect the DDJ-REV1 via the supplied USB cable and start DJing. Enjoy tactile control of various features and effects in the software by manipulating the buttons, knobs, faders, and jog wheels on the controller.

With the Scratch Bank pad mode, you can instantly load scratch samples from 4 banks that you’ve assigned in Serato DJ Lite or Pro by simply tapping the dedicated Scratch Bank button.

OTHER FEATURES

Deck 3/4 control

Play tracks and sounds loaded on any of the 4 decks in Serato DJ Lite.

Support for Serato DJ Pro

Take your performances to the next level with a free trial of Serato DJ Pro.

Class compliant

Plug your DDJ-REV1 into your PC/Mac and start DJing – there’s no need to install an audio driver.

Firmware Update Manager

You’ll be automatically notified when firmware updates become available.

Functions

• Headphones LEVEL knob Adjusts the volume of the headphones sound.
• Tempo slider Adjusts the playing speed of the track.
• TRIM knobs Adjust the volume of each channel’s sound.
• Browse section Use these controls to select tracks and load them to the decks.
• MASTER LEVEL knob Adjusts the volume of the master output sound.
• Effect lever Applies an effect while you hold the effect lever in the [ON] position, or when you set it to [LOCK ON].
• DECK select button Switches the deck to be used. Turns Vinyl mode on/off when pressing this button and SHIFT at the same time.
• AUTO LOOP button Enters Auto Loop mode.
• LOOP 1/2X, 2X button Halves/doubles the loop playback length.
• FILTER knobs Turn on the filter effect for each channel.
• Effect buttons Selects the effect of the [FX] panel.
• PAD MODE section Select and use one of 4 pad modes: HOT CUE mode, AUTO LOOP mode, TRACKING SCRATCH mode, or SAMPLER mode.
• Performance pads You can switch functions using the buttons for respective pad modes.
• Jog wheel Turn the top when Vinyl mode is on to scratch the track. Turn the outer part at any time, or turn the top when Vinyl mode is turned off, to bend the pitch. Jog wheels are noticeably bigger than the jogs on previous controllers.
• CUE button Sets, calls up, or plays a temporary cue point.
• Play/pause button Plays/pauses the track.
• Headphones output terminal Connection for your headphones. Compatible with stereo mini jack plugs (ø 3.5 mm). Only use headphones with 32 Ω or more impedance.
• USB port Connection for a PC/Mac. A USB hub can't be used.
• MASTER output terminals (RCA pin jack type) Connection for a powered speaker, a power amplifier, etc.
• MIC input terminal (1/4” TS Jack) Connection for a microphone. Only an unbalanced input can be used.
• MIC LEVEL knob Adjusts the level of sound input to the [MIC] input terminal.

What's in the box

• DDJ-REV1
• USB cable
• Warranty (for some regions)
• Quick start guide
• Precautions for use

Specifications

Main Features

Specifications

Performance Control

Fader

Terminals

* The specifications and design of this product are subject to change without notice.
